Service 04
Dimensional Inspection
From first-article approval to PPAP packages — calibrated, traceable, and visually communicated with color deviation maps.
Overview
What we deliver
When parts must match spec exactly, we deliver inspection data your quality team can defend. Every report includes full GD&T evaluation, color deviation analysis, and traceable calibration records.
Whether you need FAI for aerospace, PPAP for automotive, or routine in-process verification, we work to your standard.
Benefits
Why teams choose Axiom
GD&T compliant
Full ASME Y14.5 callout evaluation and reporting.
Non-coColor deviation mapsntact capture
Visual heatmaps make non-conformance obvious.
FAI & PPAP
Aerospace-grade first-article PPAP packages.
NIST-traceable
Equipment calibrated to national standards, daily.
Process capability
Cp, Cpk and SPC analysis for production runs.
Fast turnaround
Same-week reports for production-critical batches.
Workflow
From part to deliverable
01
Setup
Align scan to nominal CAD and datums.
02
Measure
Capture every callout per print.
03
Analyze
Compute deviations, flag non-conformance.
04
Report
PDF + native files signed by metrologist.
Ready to start your project?
Send us your part specs and timeline. We’ll respond with a quote within 24 hours.
